AI Chatbot for Shopify — Full Guide + Ready-to-use Code

Overview / TL;DR

This post shows how to add an AI chatbot to Shopify that can:

• Answer FAQs and product questions
• Suggest products (personalized recommendations)
• Look up order status (via secure server + Shopify Admin API)
• Escalate to human support

You’ll get:

1. Frontend widget (vanilla JavaScript) to embed in the storefront.
2. Secure backend (Node/Express) that proxies requests to OpenAI and the Shopify Admin API.
3. Webhook & signature verification tips and example code.
4. Security, privacy, and deployment notes.



1. Architecture (high level)

1. Shopify storefront (client) — small JS widget embedded in theme. Collects user messages and sends to your backend.
2. Your backend (server) — verifies requests, reads store data via Shopify Admin API (if needed), forwards messages to OpenAI (or other LLM), returns responses.
3. Optional: Database — store conversation logs, user context, order lookups.
4. Human fallback — bot provides option to contact human team.

Security rules:

• Never call OpenAI or Shopify Admin API directly from browser—always use your server to keep secrets safe.
• Verify incoming webhooks (Shopify HMAC).
• Rate-limit and sanitize inputs.



2. Storefront widget (vanilla JS)

Drop this into your theme (e.g., theme.liquid before </body>). It creates a chat bubble and talks to /api/chat.

<!-- chatbot-widget.html -->
<style>
  /* minimal styles */
  #ai-chatbot {
    position: fixed;
    right: 20px;
    bottom: 24px;
    width: 320px;
    max-height: 70vh;
    box-shadow: 0 8px 30px rgba(0,0,0,0.15);
    border-radius: 12px;
    overflow: hidden;
    font-family: Arial, sans-serif;
    z-index: 9999;
  }
  #ai-chatbot .header { padding:10px; background:#0b6ef6; color:white; }
  #ai-chatbot .messages { padding:12px; height:340px; overflow:auto; background:#fff; }
  #ai-chatbot .input { display:flex; padding:8px; background:#f7f7f7; }
  #ai-chatbot input { flex:1; padding:8px; border-radius:6px; border:1px solid #ddd; }
  #ai-chatbot button { margin-left:8px; padding:8px 12px; border-radius:6px; border:none; background:#0b6ef6; color:white; }
  .msg { margin-bottom:8px; }
  .msg.bot { color:#111; background:#f0f4ff; padding:8px; border-radius:8px; display:inline-block; }
  .msg.user { color:#fff; background:#0b6ef6; padding:8px; border-radius:8px; display:inline-block; float:right; }
</style>

<div id="ai-chatbot" aria-live="polite" role="dialog" aria-label="Shop assistant">
  <div class="header">Shop Assistant</div>
  <div class="messages" id="chatMessages"></div>
  <div class="input">
    <input id="chatInput" placeholder="Ask about a product, order, or size..." />
    <button id="chatSend">Send</button>
  </div>
</div>

<script>
(function(){
  const messagesEl = document.getElementById('chatMessages');
  const inputEl = document.getElementById('chatInput');
  const btn = document.getElementById('chatSend');

  function appendMsg(text, klass='bot'){
    const div = document.createElement('div');
    div.className = 'msg ' + klass;
    div.innerText = text;
    messagesEl.appendChild(div);
    messagesEl.scrollTop = messagesEl.scrollHeight;
  }

  // Optional: attach visitor context (cart, product handle) sent to backend
  function buildContext() {
    // Example: include current product handle if present (Shopify Liquid variable)
    // You can render shop/product variables into window._shopify_chat_context in theme.
    return window._shopify_chat_context || {};
  }

  async function sendMessage(message) {
    appendMsg(message, 'user');
    appendMsg('Thinking...', 'bot');
    try {
      const resp = await fetch('/api/chat', {
        method: 'POST',
        headers: { 'Content-Type': 'application/json' },
        body: JSON.stringify({
          message,
          context: buildContext()
        })
      });
      const data = await resp.json();
      // remove last "Thinking..." message
      const last = messagesEl.querySelector('.msg.bot:last-child');
      if (last && last.innerText === 'Thinking...') last.remove();
      appendMsg(data.reply || 'Sorry, I could not answer that right now.', 'bot');
    } catch (err) {
      console.error(err);
      appendMsg('Error communicating with server.', 'bot');
    }
  }

  btn.addEventListener('click', () => {
    const text = inputEl.value.trim();
    if (!text) return;
    sendMessage(text);
    inputEl.value = '';
  });

  inputEl.addEventListener('keydown', (e) => {
    if (e.key === 'Enter') btn.click();
  });

})();
</script>

Notes

• The widget calls /api/chat on your server. Implement that endpoint next.
• Optionally pre-fill window._shopify_chat_context via Liquid in theme (customer email, product handle, cart totals) — but be cautious about exposing PII.



3. Server: Node/Express backend (proxy to OpenAI + Shopify)

This is a minimal example showing:

• Accept messages from the widget
• Optionally fetch product or order info from Shopify Admin API
• Call OpenAI Chat API (or other LLM) securely
• Return a reply

Install dependencies:

npm init -y
npm i express node-fetch dotenv body-parser crypto

(You’ll need openai SDK or use fetch to OpenAI; this example uses fetch with an API key in env.)

// server.js
require('dotenv').config();
const express = require('express');
const fetch = require('node-fetch');
const bodyParser = require('body-parser');
const crypto = require('crypto');

const app = express();
app.use(bodyParser.json());

// Load environment variables
const OPENAI_API_KEY = process.env.OPENAI_API_KEY; // your OpenAI key
const SHOPIFY_ADMIN_TOKEN = process.env.SHOPIFY_ADMIN_TOKEN; // if needed
const SHOPIFY_STORE = process.env.SHOPIFY_STORE; // example: myshop.myshopify.com

// Basic rate-limit & simple abuse protection (illustrative)
const rateMap = new Map();
function rateCheck(ip) {
  const now = Date.now();
  const entry = rateMap.get(ip) || { ts: now, count: 0 };
  if (now - entry.ts > 60*1000) { entry.ts = now; entry.count = 0; }
  entry.count++;
  rateMap.set(ip, entry);
  return entry.count < 40; // e.g., 40 req/min allowed
}

// Endpoint for chat widget
app.post('/api/chat', async (req, res) => {
  try {
    const ip = req.ip || req.connection.remoteAddress;
    if (!rateCheck(ip)) return res.status(429).json({ error: 'Too many requests' });

    const { message, context } = req.body;
    if (!message || typeof message !== 'string') {
      return res.status(400).json({ error: 'Invalid message' });
    }

    // OPTIONAL: enrich prompt with Shopify data (product info / order) based on context
    let shopContext = '';
    if (context && context.product_handle) {
      // fetch product info from Shopify Admin API
      const prodResp = await fetch(`https://${SHOPIFY_STORE}/admin/api/2024-07/products.json?handle=${encodeURIComponent(context.product_handle)}`, {
        headers: { 'X-Shopify-Access-Token': SHOPIFY_ADMIN_TOKEN, 'Content-Type': 'application/json' }
      });
      if (prodResp.ok) {
        const prodJson = await prodResp.json();
        // add short product summary to prompt
        if (prodJson.products && prodJson.products.length > 0) {
          const p = prodJson.products[0];
          shopContext = `Product: ${p.title}. Short description: ${p.body_html.replace(/<[^>]+>/g,'').slice(0,200)}. `;
        }
      }
    }

    // Build messages for OpenAI ChatCompletion
    const system = `You are a helpful shopping assistant for ${SHOPIFY_STORE}. Use context from Shopify when provided. Keep responses concise, show product links when relevant.`;
    const messages = [
      { role: 'system', content: system },
      { role: 'user', content: shopContext + '\nUser: ' + message }
    ];

    // Call OpenAI (Chat Completions)
    const openaiResp = await fetch('https://api.openai.com/v1/chat/completions', {
      method: 'POST',
      headers: { 'Authorization': `Bearer ${OPENAI_API_KEY}`, 'Content-Type': 'application/json' },
      body: JSON.stringify({
        model: 'gpt-4o-mini', // replace with your model
        messages,
        max_tokens: 350,
        temperature: 0.2
      })
    });

    if (!openaiResp.ok) {
      const errText = await openaiResp.text();
      console.error('OpenAI error', errText);
      return res.status(500).json({ error: 'AI service error' });
    }

    const result = await openaiResp.json();
    const reply = result.choices?.[0]?.message?.content?.trim() || 'Sorry, I could not generate a response.';

    // Optionally store conversation in DB here

    return res.json({ reply });
  } catch (err) {
    console.error(err);
    res.status(500).json({ error: 'Server error' });
  }
});

// Example webhook endpoint to verify Shopify webhooks (for order lookup or updates)
app.post('/webhooks/shopify', express.raw({ type: '*/*' }), (req, res) => {
  const hmac = req.get('X-Shopify-Hmac-Sha256') || '';
  const secret = process.env.SHOPIFY_WEBHOOK_SECRET || '';
  const hash = crypto.createHmac('sha256', secret).update(req.body).digest('base64');
  if (!crypto.timingSafeEqual(Buffer.from(hash), Buffer.from(hmac))) {
    console.warn('Invalid Shopify webhook signature');
    return res.status(401).send('Invalid signature');
  }
  const payload = JSON.parse(req.body.toString('utf8'));
  // handle webhook...
  res.status(200).send('OK');
});

const port = process.env.PORT || 3000;
app.listen(port, () => console.log(`Server listening on ${port}`));

Important env vars

OPENAI_API_KEY=sk-...
SHOPIFY_ADMIN_TOKEN=shpat_...
SHOPIFY_STORE=your-store.myshopify.com
SHOPIFY_WEBHOOK_SECRET=...

Notes

• Use the proper Shopify Admin API version & set scopes for read_products, read_orders as needed.
• Replace gpt-4o-mini with whichever model you use and adapt request shape for your environment / SDK.



4. Example: Add order lookup command in chatbot

When a customer asks “Where’s my order?”, the bot should verify the user before revealing order status.

Flow:

1. User types “Where is my order #1001?”

2. Widget sends message + (optional) customer_email from Liquid if customer is logged in.

3. Server parses message; if it detects an order lookup intent, it:

   • Confirms with user: “Please confirm your email ending with @example.com or provide order number”
   • Calls Shopify Admin API: GET /admin/api/2024-07/orders/{order_id}.json (or search by emai
   • Returns safe order status details (no full PII).

Pseudo-code snippet (intent detection + order lookup)

// in /api/chat, after receiving message:
if (message.match(/where.*order|track.*order|order status/i)) {
  // if context contains customer email and order number, proceed
  // else ask for a confirming detail (last 4 digits of phone or email domain)
  // fetch order via Shopify Admin API (only after confirmation)
}

5. Optional: PHP backend example (lighter)

If you prefer PHP, here’s a minimal example to forward chat to OpenAI:

<?php
// endpoint: /api/chat.php
require 'vendor/autoload.php'; // if using composer
$openaiKey = getenv('OPENAI_API_KEY');

$input = json_decode(file_get_contents('php://input'), true);
$message = $input['message'] ?? '';

if (!$message) {
  http_response_code(400);
  echo json_encode(['error'=>'No message']);
  exit;
}

$system = "You are a succinct shopping assistant for mystore.";

$payload = [
  'model' => 'gpt-4o-mini',
  'messages' => [
    ['role'=>'system','content'=>$system],
    ['role'=>'user','content'=>$message]
  ],
  'max_tokens' => 300,
];

$ch = curl_init('https://api.openai.com/v1/chat/completions');
curl_setopt($ch, CURLOPT_HTTPHEADER, [
  "Authorization: Bearer $openaiKey",
  "Content-Type: application/json"
]);
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_POSTFIELDS, json_encode($payload));
$resp = curl_exec($ch);
curl_close($ch);

$data = json_decode($resp, true);
$reply = $data['choices'][0]['message']['content'] ?? 'Sorry.';
echo json_encode(['reply' => $reply]);



6. Best practices & deployment tips

Data privacy

• Store minimal PII. If storing, encrypt at rest.
• Add a visible privacy note in the chat: “This chat stores conversation for support purposes.”
• Comply with GDPR/CCPA if you operate in relevant regions.

Authentication

• Use OAuth or app access tokens for Shopify Admin API.
• Verify Shopify webhooks via HMAC signature (example included).
• Rate-limit requests to OpenAI and Shopify.

Performance

• Cache common responses (FAQ) on the server to reduce LLM calls.
• Use a smaller, cheaper model for basic Q&A and upgrade only when necessary.

User experience

• Provide suggested quick replies (e.g., “Track order”, “Return policy”, “Product size chart”).
• Show product thumbnails and direct “Add to cart” buttons when making suggestions (requires your server to supply product URL/handle).

7. Example prompt engineering (short, safe)

Use controlled prompts so the chatbot stays on-topic:

System prompt:
"You are a helpful shopping assistant for {store_name}. Keep answers short (1-3 sentences). When user asks about products, try to include product title and a short link. If the user asks for order details, ask for verification (email domain or last 4 digits of phone) before fetching order data. Never request full credit card, passwords, or other full PII."

8. Monitoring & analytics

• Log chat interactions (anonymized) to measure top intents.
• Track conversions that originated from chatbot suggestions (UTM).
• Monitor OpenAI errors and implement fallbacks.

9. Example FAQs to seed the bot (useful for fine-tuning or prompt context)

• Return policy
• Shipping times
• Size guide
• How to apply discount codes
• Store hours and contact info

Seed these into the system message or a retrieval system to improve accuracy and reduce LLM calls.



10. Final checklist before launch

• Use server-side proxy: no secrets in client code
• Implement Shopify webhook signature verification
• Limit LLM usage and add caching
• Provide human fall-back option
• Add privacy notice & logging policy
• Test flows: FAQ, product recommendation, order lookup
